Automotive Grade High Current Jumper Chip Resistor |
High current jumper, automotive grade, and anti-sulfur. Sizes 0201 to 2512, high current handling up to 70.7 amps. AEC-Q200 qualified. |
 |
|
 |
Molded Metal Plate Sensing Resistor |
The high power metal alloy current sense resistor comes in value ranges from 0.001 to 0.1 ohm in 0603 and 2512 size and TCs of 50 and 100 ppm. Tolerances of 1% and 5%. Power rating of 3 W. Package size 2512 is qualified to AEC-Q200. |
|
|
 |
Foil on Ceramic Current Sensing Surface Mount Chip Resistor |
Sizes from 0402 to 4320, tolerances of 1% and 5%, ohmic values from 0.002Ω to 0.6Ω, TCs down to 50ppm with low inductance and high current handling. Package sizes 0402(HP), 0603(HP), 0805, 1206, and 2512 are qualified to AEC-Q200. |
|
|
|
Thick Film Current Sensing Surface Mount Chip Resistor, Narrow |
Size 0815, 2010 and 2512, Tolerances 1%, 2% & 5%, TC as low as 150ppm, values 0.01Ω to 1Ω. CSRN2512 is qualified to AEC-Q200. |
|
|
 |
Ultra Precision Current Sensing Chip Resistor |
The High Power Metal Foil construction comes in value ranges from 0.00025Ω up to 0.19Ω in sizes from 0201 to 4527 with TCR as low as 15 ppm. Tolerances of 0.5 to 5%. Power ratings range from 0.2 to 5 Watts. Qualified to AEC-Q200. |
|
|
 |
Ultra Precision Current Sensing Chip Resistor |
The High Power Metal Alloy construction comes in value ranges from 0.0003 up to 0.08 ohms in sizes 0805, 2512 and 2728 at as low as ± 15 ppm . Tolerances of 0.5% to 5%. Power ratings of 1, 3 and 4 Watts. Qualified to AEC-Q200. |
|
|
 |
Kelvin Terminated Current Sensing Resistor |
Metal Alloy construction with 4 terminal Kelvin terminations comes in value ranges from 0.00055 up to 0.005 ohms in 0612 size. Power rating of 1 W. AEC-Q200 compliant. |
|
|
 |
Surface Mount High Current Jumper Chip Resistor |
Sizes from 0402 to 2512, max. resistance value less than 3 milliohm for 0402 and less than 0.5 milliohm for other sizes. Current handling from 6.5A up to 63.2A. Qualified to AEC-Q200. |
|
|
 |
High Current Shunt Resistor |
Sizes of 1206, 2512, 3920 and 5930. Available in 1.5W to 10W power ratings. Resistance value of 0.2, to 5 milliohms. Current handling up to 224A in 5930 size. Qualified to AEC-Q200. |
|
|
 |
High Power Current Shunt Resistor |
Size 2818, available in 5W power rating. Resistance values of 2, 3, 4, 5, 10, 15, 20 and 25 milliohms. TCR of 75, 100 and 200 ppm/C. AEC-Q200 compliant. |
|
|
 |
Metal Film Melf Resistor - AEC-Q200 Qualified |
Sizes of 0102, 0204 and 0207, power ratings of 0.3W, 0.4W and 1W, tolerances of 0.1% to 5%, values of 0.1Ω to 1MΩ, TCs down to 15ppm. Qualified to AEC-Q200. |
|
|
 |
Thick Film Surface Mount Chip Resistor Array Convex Terminations |
Sizes from 0402x2,4 0603x2,4,8, 1206x4,8 , Tolerances 1, 2 and 5%, values 1Ω to 1MΩ. Styles 102D, 104D and 164D are qualified to AEC-Q200. |
|
|
 |
Semi-Precision Thick Film Surface Mount Resistor |
Size of 0201 to 2512, Tolerances of 0.1%, 0.5% and 1%, Ohmic values of 1Ω to 10MΩ. With TC's of 50 to 200ppm. 0402 and 0603 are qualified to AEC-Q200. |
|
|
 |
General Purpose Thick Film Surface Mount Chip Resistor |
Sizes from 01005 to 2512; tolerances of 1% and 5%; Ohmic values from 0.1Ω to 20MΩ; with TC's of 100 to 600ppm. AEC-Q200 compliant, except sizes 01005 and 0201. |
|
|
 |
General Purpose High Power Thick Film Chip Resistor |
Sizes from 0201 to 2512. High Power capabilities handling 2W up to 7A at 500V. Tolerances of 1% and 5%. Resistance ranges from 1Ω to 1MΩ and TCR as low as 100 ppm. Package sizes 0402 through 2512 are AEC-Q200 compliant. |
|
|
 |
Automotive Grade Anti-Sulfur Thick Film Chip Resistor - RoHS Compliant Without Exemption |
Sizes from 0402 to 2512, tolerances of 0.5%, 1% and 5%, ohmic values from 1 ohm to 10 Mohm, with TC's of 100 and 200 PPM/C, and power rating up to 1.5W. AEC-Q200 qualified. |
|
|
 |
Thick Film Chip Resistor - 100% RoHS Compliant Without Exemption |
Sizes from 0402 to 2512, tolerances of 0.1%, 0.5%, 1% and 5%, ohmic values from 1 ohm to 10 Mohm, with TC's of 100 to 400 ppm. AEC-Q200 compliant. |
|
|
 |
Automotive Grade Anti-sulfur and AEC Qualified Thin Film Chip Resistor |
Size of 0402 to 1206, tolerances of +/-0.05% to 1%, values of 4.7 ohms up to 1.5 Megaohms. TCR as low as +/- 10 ppm. Automotive Grade Anti-sulfur and AEC-Q200 compliant. |
|
|
 |
Precision Thin Film Surface Mount Chip Resistor |
Size of 0201 to 2512, tolerances of 0.01% to 1%, values of 1Ω to 3MΩ, TCR of 2 to 50ppm with tighter tolerances available upon request. Qualified to AEC-Q200. |
|
|
 |
Moisture Resistant Precision Thin Film Chip Resistor |
Size of 0603, 0805 and 1206, tolerances of 0.1% to 0.5%, values of 25Ω to 1MΩ, TCs of 15, 25 and 50ppm. Replaces costly Tantalum Nitride resistors for moisture sensitive applications. Qualified to AEC-Q200. |
|
|
 |
Thin Film High Power Anti-surge Chip Resistor |
Sizes of 1206, 1210, and 2512 tolerances from 0.5% to 5%, values from 0.05 to 0.976 ohms TCs of 50 and 100 ppm. Low Inductance, Anti-Surge. AEC-Q200 qualified. |
|
|
 |
Moisture Resistant Precision Thin Film Chip Resistor |
Size of 0402 to 2512, tolerances of 0.1% to 0.5%, values of 10Ω to 1MΩ, TCs of 15, 25 and 50ppm. Replaces costly Tantalum Nitride resistors for moisture sensitive applications. Qualified to AEC-Q200. |
|
|
 |
Ultra-High Power Thin Film Chip Resistor |
Size 1206, tolerance of 0.1% to 1%, values of 10 to 100K ohm, TCR as low as 10 ppm. AEC-200 compliant. |
|
|
 |
Automotive Grade High Voltage Thin Film Chip Resistor |
Sizes of 0805, 1206 and 1210, tolerances of 0.1% to 1%, values of 121 Kohms to 3.01 Mohms, TCs of 25 and 50 ppm. Anti-sulfur. AEC-Q200 qualified. |
|
|
 |
Automotive Grade High Temperature Thin Film Chip Resistor |
Automotive Grade High Temperature Thin Film Chip Resistor in 0402 to 1206 sizes, tolerances from 0.02% to 0.5%, with TCRs from 5ppm to 100ppm. AEC-Q200 qualified. |
|
|
 |
Pulse Withstanding Thick Film Surface Mount Chip Resistor |
Sizes from 0402 to 2512; Tolerances from 0.5% to 20%; Ohmic values from 1Ω to 20MΩ with excellent pulse handling capabilities. 1% and wider tolerances are qualified to AEC-Q200. |
|
|
 |
Automotive Grade High Temperature Thin Film Chip Resistor |
Automotive Grade High Temperature Thin Film Chip Resistor in 0402 to 1206 sizes, tolerances from 0.02% to 0.5%, with TCRs from 5ppm to 100ppm. AEC-Q200 qualified. |
|
|
 |
Tantalum Nitride Thin Film Chip Resistor |
Sulfur resistant, self-passivating technology impervious to moisture. Sizes from 0402 to 1206, available in 0.05% to 1% tolerances with resistance ranges from 10Ω to 1MΩ and TC's of 10 ppm to 50 ppm. Qualified to AEC-Q200. |
|
|
 |
Automotive Grade High Voltage Thick Film Chip Resistor |
Automotive grade AEC-Q200 qualified surface mount chip resistors with 1% and 5% tolerances ranging from 30K to 100M ohms in sizes from 0402 to 2512. |
|
